MULTI-PLY FABRIC CONVEYOR BELT
NYLON CONVEYOR BELT
Belt elasticity is high,tensile strength is high too.It resists impact and has excellent flexibility resistance and troughability.Apart from these,its elongation is small,so suitable for middle and long distance transportation of higher load and speed.The reinforcement is made from nylon 6,nylon 66.The reinforcement made from nylon 66 has a better stability of dimention operated under a high temperature.
EP CONVEYOR BELT
Belt modulous is high.Small elongation under operation and good thermal stability as well as impact resistance..This belt is suitable for middle and long distance transportation of materials,one is E P and the other is D S E P.The D S E P is of high module and low shrink,its dimention stability will be much better under normal and high temperature.
Application:
Can be used widely in coal industry,mines,ports,metallurgical industry power plant and chemical etc.for conveying materials.
|
Kind of Carcass |
Type of Carcass |
Tensile strength of monoply |
thickness of coated Fabric |
Weight of Coated Fabric |
|
N/mm * P |
Lbs/in * P |
mm |
in |
kg/m2 |
ib/ft2 |
|
Polyester(Warp)
+
Nylon(Weft) |
EP - 100 |
100 |
560 |
0.80 |
0.031 |
1.05 |
0.22 |
|
EP - 125 |
125 |
700 |
0.90 |
0.035 |
1.15 |
0.24 |
|
EP - 150 |
150 |
840 |
1.10 |
0.043 |
1.25 |
0.26 |
|
EP - 200 |
200 |
1120 |
1.25 |
0.049 |
1.35 |
0.28 |
|
EP - 250 |
250 |
1400 |
1.30 |
0.051 |
1.65 |
0.34 |
|
EP - 300 |
300 |
1680 |
1.70 |
0.067 |
1.80 |
0.37 |
|
EP - 400 |
400 |
2240 |
1.85 |
0.073 |
2.10 |
0.43 |
|
EP - 500 |
500 |
2800 |
2.15 |
0.085 |
2.55 |
0.52 |
|
EP - 600 |
600 |
3360 |
2.60 |
0.102 |
2.85 |
0.58 |
|
Nylon(Warp)
+
Nylon(Warp) |
NN - 100 |
100 |
560 |
0.75 |
0.030 |
0.85 |
0.17 |
|
NN - 125 |
125 |
700 |
0.85 |
0.033 |
0.90 |
0.18 |
|
NN - 150 |
150 |
840 |
0.90 |
0.035 |
1.10 |
0.23 |
|
NN - 200 |
200 |
1120 |
1.10 |
0.043 |
1.25 |
0.26 |
|
NN - 250 |
250 |
1400 |
1.25 |
0.049 |
1.30 |
0.27 |
|
NN - 300 |
300 |
1680 |
1.50 |
0.059 |
1.60 |
0.33 |
|
NN - 400 |
400 |
2240 |
1.70 |
0.071 |
1.95 |
0.40 |
|
NN - 500 |
500 |
2800 |
2.00 |
0.079 |
2.30 |
0.47 |
|
NN - 600 |
600 |
3360 |
2.20 |
0.087 |
2.65 |
0.54 |
|
Belt Tensile strength at Break |
maximum working strength |
Fabric kind of carcass |
minimum diameter of head and drive pulley(mm) |
|
N/mm |
Lbs/in |
N/mm |
Lbs/in |
2ply |
3ply |
4ply |
5ply |
6ply |
7ply |
|
200 |
1120 |
20 |
112 |
NN |
200 |
|
|
|
|
|
|
EP |
200 |
|
|
|
|
|
|
250 |
1400 |
25 |
140 |
NN |
200 |
|
|
|
|
|
|
EP |
200 |
|
|
|
|
|
|
315 |
1764 |
31 |
176 |
NN |
200 |
300 |
|
|
|
|
|
EP |
300 |
350 |
|
|
|
|
|
400 |
2240 |
40 |
224 |
NN |
250 |
350 |
400 |
|
|
|
|
EP |
350 |
400 |
450 |
|
|
|
|
500 |
2800 |
50 |
280 |
NN |
250 |
350 |
400 |
450 |
|
|
|
EP |
350 |
400 |
450 |
600 |
|
|
|
630 |
3530 |
63 |
353 |
NN |
300 |
350 |
400 |
450 |
550 |
|
|
EP |
400 |
500 |
600 |
700 |
700 |
|
|
800 |
4480 |
80 |
448 |
NN |
|
400 |
450 |
500 |
550 |
650 |
|
EP |
|
600 |
700 |
750 |
800 |
850 |
|
1000 |
5600 |
100 |
560 |
NN |
|
450 |
500 |
550 |
600 |
700 |
|
EP |
|
700 |
800 |
850 |
900 |
950 |
|
1250 |
7000 |
125 |
700 |
NN |
|
550 |
600 |
700 |
700 |
800 |
|
EP |
|
800 |
900 |
1000 |
1050 |
1100 |
|
1600 |
8960 |
160 |
896 |
NN |
|
|
650 |
750 |
750 |
800 |
|
EP |
|
|
950 |
1050 |
1150 |
1300 |
|
2000 |
11200 |
200 |
1120 |
NN |
|
|
650 |
800 |
900 |
900 |
|
EP |
|
|
950 |
1050 |
1250 |
1300 |
|
2500 |
14000 |
250 |
1400 |
NN |
|
|
|
950 |
1050 |
1150 |
|
EP |
|
|
|
1200 |
1350 |
1650 |
|
3150 |
17640 |
315 |
1764 |
NN |
|
|
|
1150 |
1150 |
1200 |
|
EP |
|
|
|
1350 |
1500 |
1750 |
|
Serial No |
Tensile Strength at break |
Elongation at Break % |
Abrasion mm 3 |
Standards Adopted |
Features |
|
N/mm2 |
PSI |
|
1 |
25 |
3560 |
450 |
120 |
DIN22102-X.AS1332-M.SABS117-3-M |
High Tension Strength Type |
|
2 |
20 |
2850 |
400 |
150 |
DIN122102-Y |
Higher Tension Strength Type |
|
3 |
18 |
2560 |
450 |
200 |
JISK6322-S.BS490-N.MRA-1.SABS1173-NASI1332-N |
Tensile Strength Type |
|
4 |
18 |
2560 |
400 |
90 |
DIN22102-W |
High Abrasion Type |
|
5 |
17 |
2430 |
400 |
70 |
AS1332-A |
High Abrasion Type |
|
6 |
15 |
2140 |
400 |
250 |
DIN22102-Z, JISK6322-G |
General Type |
|
7 |
14 |
2000 |
400 |
150 |
JISK6322-A,RMA-2 |
General Type |
|
8 |
14 |
2000 |
300 |
250 |
AS1332-S |
Antistatic Type |
|
9 |
14 |
2000 |
300 |
---- |
AS1332-F.E |
Fire Resistant and Antistatic Type |
|
10 |
10 |
1430 |
350 |
---- |
TISK6324 RMA/RAC809 |
Fire Resistant Type |
|
11 |
8 |
1140 |
300 |
400 |
JISK6322-L |
Light Duty Type | |
|
